#Altera quartus ii 9.1 install
Note: of course, to work with Cyclone III, you can install an older version of Quartus than 13.1, however, an attempt to install some older version like 9.1 may reveal the absence of some ancient system libraries in the modern version of Debian, and deal with these without good reason oh how I do not want to.įor users of other boards, I’ll say that you can find out which version of Quartus is required to work with your FPGA here.
Thus, to cover all the boards of the Mars rover family, you will have to install two Quartus versions at once: 13.1 and 15.0. I will only clarify that both relatively old and the latest versions of Quartus are suitable for working with the MAX II.Īs you can see, using the only Quartus version to work with all Mars rover boards will not succeed: on the one hand, the Mars rover2 board is built on the relatively old Cyclone III FPGA, and the latest Quartus versions do not work with such an old FPGA on the other hand, the Mars rover3 and Mars rover3bis boards are built on the FPGA of the latest MAX10 family, the existence of which older versions of Quartus do not know. Note: the Mars rover board is not included in the table the MAX II FPGA used in it belongs to a completely different class than the Cyclone and MAX10 FPGAs. Let's compare the boards of the Mars rover family: I will clarify that at the time of this writing, the latest version was Quartus 15.0.
If you suddenly need to work with FPGAs of old families, then most likely you will have to look for the old version of Quartus. It should be borne in mind that Quartus CAD (even the Subscription Edition) does not support all the FPGAs that Altera has ever released, but only relatively modern ones. Preliminary calculations: which FPGA will we work with? However, the Mars rover boards (and generally inexpensive boards) are made on the basis of the FPGAs of the Cyclone, MAX10 and MAX II families, and these families are supported by Quartus Web Edition.
#Altera quartus ii 9.1 free
In the future, exclusively Web Edition is considered - this is a free option, however, it has a number of limitations, and not all Altera FPGA families are supported. Subscription Edition is a paid option that allows you to work with all FPGAs that Altera produces You can familiarize yourself with the cost of the Subscription Edition here.
Preliminary calculations: pay or not pay?Īt first glance, it’s not obvious, but not all Quartus are equally useful in other words, what is allowed to Quartus of one version is completely not necessarily allowed to Quartus of another version.įirst things first, you should immediately realize that there are two versions of Quartus CAD: Subscription Edition and Web Edition. However, before installing Quartus, it is necessary to make preliminary calculations - to determine what Quartus will be used for and to clarify under which OS we will run Quartus. In order to make the installation completely uncomplicated, the corresponding scripts were written (see below) and this publication was created.
prepare a configuration in a text file / script, start the installation and do other things, and not wait for the installer to deign to ask his new, unexpected question. Separately, I was very upset by the inability to install Quartus in batch mode - i.e. Having downloaded several versions of Quartus for Linux from the Altera website, I was convinced that installing Quartus is not something very complicated, but at first it can be difficult: the number of versions of this Quartus is large, you need to manipulate gigabyte files - make a mistake pretty easy.
#Altera quartus ii 9.1 manual
has Quartus installation instructions., however, more than 5 years have passed since the publication of this manual, and in addition, the manual describes the installation of Quartus for Windows. The material will be useful to everyone who starts working with Quartus under the GNU / Linux OS. The author uses Quartus to work with boards of the Mars rover family, so the publication also gives a small overview of this family, and what versions of Quartus are suitable for which Mars rover boards.
#Altera quartus ii 9.1 how to
The publication describes how to install Altera Quartus II Web Edition (hereinafter simply Quartus) CAD software in batch mode on a computer running Debian Linux amd64.
